Description
High compaction force combined with fast forward and reverse travel means the BPU 5545A achieves great productivity. It is an all-around versatile plate for all job sites that place high demands on the machine's performance potential. Its other outstanding characteristics are high operator comfort and a long service life. It is perfectly suited for the compaction of building back-fill, and of frost and sub bases when constructing roads, paths and parking lots. The 69 Hz frequency makes the BPU 5545A suitable for all purposes and compacts even medium-weight and heavy interlocking paving stone reliably. Infinitely variable forward and reverse operation including spot compaction for easy maneuverability. Ideal for trenches and large spaces.
Specifications
Manufacturer
Wacker Neuson
Model
BPU5545A
Year
2022
Category
Compactors
Subcategory
Reversible Vibratory Plates
Advance travel max. (depending on soil & environmental factors)
27 m/min
Base plate size (W x L)
440 x 900 mm
Base plate thickness
0.47 in
Centrifugal force
12,364 lbf
Frequency
69 Hz
Fuel consumption
0.53 US gal/h
Hand-arm vibrations
4.9 ft/s²
Surface capacity max. (depending on soil & environmental factors)
9,171 ft²/h
Height (without guide handle)
28.3 in
Operating weight
750 lb
Operating width (with extension plate)
23.6 in
Transport height
59.6 in
Transport length
41.3 in
Transport width
30.7 in
