Description
Hyundai large breakers are suited to fit excavators ranging from 30 ton to 80 ton. If equipped on a Hyundai excavator, standard equipped mounting brackets are designed to match up perfectly with the Hyundai linkage. If you would like to use on another brand of excavator, Hyundai dealers can match a custom mounting bracket to fit any machine.
Specifications
Manufacturer
Hyundai
Model
Large Breakers
Year
2023
Category
Breakers
Subcategory
Large Breakers
Operating Weight (Top Box Bkt.)
2,832 Kg (6,243 Lbs) ~ 5,625 Kg (12,401 Lbs)
Chisel Outer Dia.
150 Mm (5.9 In) ~ 200 Mm (7.9 In)
Setting Pressure
210 Kgf.Cm2 (2,987 Psi) ~ 240 Kgf.Cm2 (3,414 Psi)
Working Pressure
140~180 Kgf.Cm2 (1,991~2,560 Psi) ~ 150~190 Kgf.Cm2 (2,134~2,702 Psi)
Blow Rate (H/ Speed)
200~350 (300~480) ~ 230~370 (300~480) Bpm
Suitable Excavator
26~100 Tons (57,320~22,0462 Lbs)
Impact Power
8,550 Ft.Lbs (11,600 J) ~ 16,200 Ft. Lbs (22,000 J)
Oil Flow
180~250 Ipm (47.6~66.0 Gpm) ~ 320~450 Ipm (322~119.9 Gpm)
