Description
Hyundai excavators are known for fast cycle speeds, impressive hydraulic power and precision control. Adding to that success formula, the Hyundai HX series features eco-friendly, high-performance engines that meet Tier 4 Final emission requirements. At Hyundai, reliable productivity is more than just a promise. The robust upper and lower frame structure can endure external shock and heavy workloads for many thousands of hours. HX series is designed with the operator in mind. A key feature of the new operator's cab in each HX series excavator is the convenient clustering of electronic controls and monitoring functions, resulting in improved operator accuracy and efficiency.
Specifications
Manufacturer
Hyundai
Model
HX260L
Year
2023
Category
Excavators
Subcategory
Crawler Excavators
Operating Weight
26,700 Kg (58,860 Lbs)
Swing Speed
10.8 Rpm
Bucket Breakout Force
18200 [19760] Kgf ( 40120 [43560] Lbf ) ISO
Arm Crowd Force
12100 [13140] Kgf ( 26680 [28970] Lbf ) ISO
Engine Model
Cummins Qsb6.7
Net Power
179 Hp (133 Kw) At 1,950 Rpm
Travel Speed (Mph)
5.8 Km/Hr (3.60 Mph) / 3.4 Km/Hr (2.11 Mph)
Bucket Range
1.41 Yd3 - 1.96 Yd3 1.08 M3 - 1.50 M3
Max. Digging Depth (Ft/In)
7,000 Mm (23 Ft)
Max. Digging Reach
10,360 Mm (34 Ft)
Tail Swing Radius (Ft/In)
2,975 Mm (9 Ft 9 In)
