Description
Mustang 2550RT
Specifications
Manufacturer
Mustang
Model
2550RT
Year
2023
Category
Loaders
Subcategory
Track Loader
Operating Capacity at 35% of Tipping Load (kg)
2,550 lbs (1157)
Operating Capacity at 50% of Tipping Load (kg)
3,643 lbs (1652)
Tipping Load (kg)
7,286 lbs (3305)
Operating Weight (kg)
11,600 lbs (5260)
Auxiliary Hydraulic Flow - Rated Speed (L/min)
29.07 gpm (110)
High-Flow Hydraulic Flow - Rated Speed (L/min)
37.7 gpm (142.7)
Transmission Pump Type
Axial Piston
Motor Type
Axial Piston with Planetary Reduction
Make/Model
Deutz/ TD 3.6 L4 Tier IV
Type
4-Stroke Turbo
Displacement (L)
221 cu.in. (3.621)
Cylinders
4
Net Horsepower (kW) @ 2500 rpm
70.7 hp (52.7) @ 2300
Peak Torque (Nm) @ 1600 rpm
243 ft.-lbs (330) @ 1600
Oil Pump Capacity (L)
11 qts. (10.4)
Alternator Voltage/Amperage
12V/120A
Drawbar Pull / Tractive Effort (kN)
12,453 lbs (5649)
Track Type
Rubber
Track Rollers
5
Roller Type
Steel
Ground Pressure (bar)
5.2 psi (0.36)
Forces Bucket Breakout - Tilt Cylinder (kg)
8,384 lbs (3803)
Forces Bucket Breakout - Lift Cylinder (kg)
7,437 lbs (3373)
Forces Ground Speed - Single Speed (km/hr)
5.3 mph (8.5)
Forces Ground Speed - Two Speed (km/hr)
7.5 mph (12.1)
Overall Operating Height - Fully Raised (mm)
168 (4267)
Height to Hinge Pin - Fully Raised (mm)
128 (3251)
Reach - Fully Raised (mm)
34.5 (876)
Dump Height - Fully Raised (mm)
98 (2489)
Overall Height at ROPS (mm)
83.1 (2111)
Overall Length with Bucket - Standard Counterweight (mm)
157.8 (4008)
Overall Length without Bucket - Standard Counterweight (mm)
126.8 (3221)
Specified Height (mm)
67.7 (1720)
Reach at Specified Height (mm)
31.3 (795)
Carry Position (mm)
8.2 (208)
Digging Position - Below Ground (mm)
+0.5 (13)
Ground Clearance (mm)
12.3 (313)
Track Gauge (mm)
51.7 (1313)
Track Shoe Width (mm)
17.7 (450)
Crawler Base (mm)
61.5 (1562)
Overall Width - Less Bucket (mm)
69.5 (1765)
Bucket Width (mm)
83.9 (2131)
Clearance Radius - Front with Bucket (mm)
98.4 (2499)
Clearance Radius - Rear with Standard Counterweight (mm)
70.7 (1796)
Grouser Height (mm)
1 (25)
Track Drives Track Width (mm)
17.7'' (450)
Dump Angle - Fully Raised
41deg
Maximum Rollback Angle - Fully Raised
102.5deg
Dump Angle at Specified Height
66.8deg
Maximum Rollback Angle at Ground
30deg
Maximum Rollback Angle at Carry Position
31.6deg
Angle of Departure with Standard Counterweight
25deg
Maximum Rollback at Specified Height
66.8deg
Angle of Approach
90deg
Fuel Tank (L)
32 gal. (121.1)
Hydraulic Reservoir Tank (L)
13.8 gal. (52.2)
Coolant Capacity (L)
6.1 gal. (23.1)
