Description
Wacker Neuson's DT08 track dumper with its compact dimension and precision control can be maneuvered with pin-point accuracy along any surface. Its 1,764 lb (800 kg) payload and width of only 31 in (79 cm) make the DT08 ideal for rental applications. Powered by a Honda gasoline engine and comes with a front tip skip.
Specifications
Manufacturer
Wacker Neuson
Model
DT08
Year
2024
Category
Dumpers
Subcategory
Track Dumpers
Payload max
800 kg
Skip capacity level
334 l
Skip capacity heaped*
387 l
Travel speed max
4 km/h
Length (without running board)
1,660 mm
Length with self-loading equipment (without running board)
2,132 mm
Length of running board
388 mm
Height over running board
235 mm
Width Undercarriage
790 mm
Skip width
830 mm
Skip length
1,320 mm
Width with self-loading equipment
830 mm
Chain width Track
180 mm
Length Track
753 mm
Height over control console
1,240 mm
Height over skip hand protector
1,313 mm
Height of skip front edge
750 mm
Dump height max
420 mm
Height max, skip raised
1,845 mm
Dump angle Skip dumping
72 °
Bucket rollback Running board retraction
14 °
Ground clearance
110 mm
Rubber track width
7.1"(180 mm)
Max height skip raised
72.6"(1845 mm)
Drop height (front lip of skip to ground when dumping)
16.5"(420 mm)
Length / width / height
65.4"(1660 mm) / 31.1"(790 mm) / 51.7"(1180 mm)
L x W x H *
1,660 x 790 x 1,203 mm
