Description
LTW20 Wide Body Vertical Mast Light Towers: wide light towers perfect for off road towing and far away places
The standard five-section vertical mast light tower is power actuated, extending 23 feet and can rotate 360 degrees for optimum lighting flexibility. The wide body design features a proven engine, long run fuel tank and DOT trailer lights. The light bar design creates greater flexibility in directing the four light fixtures for greater light coverage on the jobsite. Choice between conventional 4 x 1100 Watt Metal Halide (MH) or energy-efficient 4 x 300 Watt LED lights. The wide body vertical mast light towers are perfect for remote applications including oil and gas worksites, mining, and industrial applications.
Specifications
Manufacturer
Wacker Neuson
Model
LTW20Z1, MH
Year
2024
Category
Light Towers
Subcategory
Light Towers
Nominal current
78 A
Nominal voltage
120 V
Nominal frequency
60 Hz
Nominal power [P]
18.6 KW
Nominal power [S]
20.9 kVA
Phase
1 ~
Operating weight
3,450.2 lb
Output frequency
60 Hz
Voltage Regulation - Steady State
0.005
Generator Rating 1~ (Continuous)
21 KW
Generator Rating 3~ (Continuous) One
36 KW
Generator Manufacturer
Mecc Alte
Generator specification
AVR without Brushes
Cylinder
4,0
Cylinder capacity
133 Inch3
Tank capacity
57 gal US
Oil filling max.
2.7 gal US
Power rating max.
40.2 hp
Effective power
31.5 hp
Starter battery Voltage
12 V
Battery Cold-start current CCA
750 A
Running time at 100%
34.8 hrs
Main Circuit Breaker Rating
80 A
Bulb power
1,100 W
Receptacle Type
NEMAL5-20R,TL,125V,20A
Cooling fluid volume
13.3 qt US
Shipping weight
3,040.2 lb
Illuminance
5 fc
Coverage area
9,224.7 ft2
NEMA Beam Spread
Type 6
Length
131.1"
Width
75.6"
Height
100"
Mast height max.
23 Foot
Length for shipping
103.5"
Width for shipping
75.6"
Height for shipping
100"
