Description
SW32 Skid Steer Loader: Productivity PersonifiedThe SW32 is the most powerful and largest Skid Steer Loader in the Wacker Neuson product line. Versatile and comfortable, the SW32, has the speed and control to maximize efficiency. Equipped standard with 2-speed and a color 5.7" multi-function display, allowing in-cab control customizations, the SW32 will enhance productivity on any jobsite.
Specifications
Manufacturer
Wacker Neuson
Model
SW32
Year
2024
Category
Skid Steers
Subcategory
Skid Steer Loaders
Break Out Force Bucket
7,932.4 lbf
Break Out Force Lift Arm
9,371.4 lbf
Tractive Effort max at 100% effective force
9,711.7 lbf
Travel speed stage 1
7.3 m/H
Travel speed stage 2
12.2 m/H
Cylinder
4,0
Cylinder capacity
205 Inch3
Operating power
100.6 hp
Operating Engine speed
2,500 1/min
Battery capacity (nom. value)
950 Ah
Engine type
Diesel engine
Manufacturer
Kohler
Flow rate
25.1 gal/mi
Flow rate max
37.2 gal/mi
Auxiliary relief pressure
3,494.5 psi
Fuel Tank capacity
39.9 gal
Tip Load
6,400 lb
Rated Operating Capacity at 50% Tip Load
3,198.9 lb
Overall Length without bucket
117.5
Overall Length with Bucket
145.4
Overall width without bucket
71.9
Overall height to top of ROPS
83.2
Bucket Hinge Pin Height
134.8
Angle of departure
23 °
Bucket dump height at maximum height
107.8
Bucket dump angle at maximum height
44 °
Operating weight
8,628.9 lb
Ground clearance
9 in
Wheelbase
49.9 in
Overall length with bucket
145.4 in
Overall length without bucket
117.5 in
Hinge pin height
134.8 in
Dump height max
107.8 in
