Description
The medium-weight reversible vibratory plates offer high productivity as a result of its high compaction force in combination with fast forward and reverse travel speeds. They are the all-rounders for all construction sites where high demands are placed on the performance efficiency of a unit. In addition, they offer excellent characteristics in terms of long service life and operating comfort. Optimal application areas are the compaction of frost layers and subbases in street, path and parking lot construction as well as backfilling around buildings. Due to the frequency of 69 Hz, the medium-weight reversible vibratory plates are versatile for many jobs including the compaction over medium and heavy interlocking paving stones. 300 - 600 kg Medium-weight reversible vibratory plates: Unbeatable on any surface.
Specifications
Manufacturer
Wacker Neuson
Model
BPU 4045A US
Year
2024
Category
Compactors
Subcategory
Reversible Vibratory Plates
Length Baseplate
35.4 "
Width
23.8 "
Width Baseplate
17.3 "
Height
51.5 "
Height Cover frame
28.5 "
Thickness Baseplate
0.5 "
Ground Clearance
28.5 - 33.8 "
Centrifugal Force
8,992 lbf
Area Capacity
9,364.7 ft2/h
Gradeability
36.4 %
Operating Weight
747.4 lb
Effective Power
6.8 hp
HAV summation (average value)
8.2 ft/s2
HAV summation (standard)
EN 500-4
Nominal Engine Speed
2,600 1/min
