Description
Wacker Neuson dual power is the innovative solution for an emission free auxiliary drive In addition to the integrated diesel engine the electro hydraulic unit HPU8 can be connected to the 803 compact excavator if necessary The HPU8 is technically tailor made to the requirements of the excavator 803 In this way the excavator can be operated electrically and emission free if necessary The handling is easy The generator is connected to the undercarriage via Plug Play done
Specifications
Manufacturer
Wacker Neuson
Model
803 dual power
Year
2025
Category
Excavators
Subcategory
Tracked Conventional Tail Excavators
Arm displacement to centre of bucket, left side
11.1 in
Arm displacement to centre of bucket, right side
9.6 in
Biting force max
1,012 lbf
Boom slewing radius
42.7 in
Breakout force max
2,001 lbf
Cabin - specified sound pressure level LpA
77 dB(A) LpA
Chain width
7.1 in
Digging depth max
69.4 in
Digging radius max
121.7 in
Dump height max
79.2 in
Dumping height
79.2 – 80.1 in
Duty pump
Gear pumps
Insertion depth
52 in
Insertion height
112.7 in
Lift height - Above ground
7.8 in
Operating pressure Slewing gear
1,015 psi
Range
119.3 in
Rear swivel radius
29.4 in
Scraping depth - Below ground
7 in
Sound level (LwA) according to 2000/14/EC
93 dB(A)
RPM / speed Revolving superstructure
8 rpm
Stroke - Above ground
7.76 in
Stroke - Below ground
6.85 in
Travel speed
1.1 mph
Turning angle - Boom system to the left
55 degrees
Turning angle - Boom system to the right
56 degrees
Width - Undercarriage extended
33.9 in
