Description
Hyundai small breakers are suited to fit compact size excavators ranging from 1.7 ton to 8 ton. If equipped on a Hyundai compact excavator, standard equipped mounting brackets are designed to match up perfectly with the Hyundai linkage. If you would like to use on another brand of excavator, Hyundai dealers can match a custom mounting bracket to fit any machine.
Specifications
Manufacturer
Hyundai
Model
HDB40
Year
2024
Category
Breakers
Subcategory
Small Breakers
Operating Weight (Top Box BKT)
224 kg (493 lb)
Operating Weight (Side BKT)
162 kg (357 lb)
Impact Power
600 Ft Lbs (820 J)
Suitable Excavator
3~5 ton (6614~9921 lb)
Overall Length (w/STD MTG BKT)
1408 mm (54.4 inch)
Overall Length (w.o/MTG BKT)
1258 mm (49.5 inch)
Overall Length (Side BKT)
1192 mm (46.9 inch)
Chisel Out Dia
62 mm (2.4 inch)
Chisel Length
610 mm (24 inch)
Setting Pressure
150 kgf/cm<sup>2</sup> (2134 psi)
Working Pressure
100~140 kgf/cm<sup>2</sup> ( 1422~1991 psi)
Oil Flow
30~50 lpm (7.9~13.2 gpm)
Blow Rate (H/ Speed)
500~1000 BPM
Back Head N2 Gas Pressure
12 kgf/cm<sup>2</sup> (171 psi)
