Description
The Hyundai wheeled excavator product line includes three HW series models and one 9A series compact model to give you an edge in a wide range of on-road and off-road applications. These Tier 4-Final-compliant wheeled excavators deliver improved performance, increased fuel efficiency, superior travel speeds on the road, an enhanced cab and added safety features.
Specifications
Manufacturer
Hyundai
Model
HW140AL
Year
2025
Category
Excavators
Subcategory
Wheeled Excavators
Operating Weight
35,053 LBS (15,900 kg)
Bucket Breakout Force
11,746 [12,810] kgf / 25,900 [28,240] lbf
Arm Crowd Force
7,401 [8,070] kgf /16,320 [17,790] lbf
Net Power
170 HP (127 kW) / 2,200 rpm
Maximum Travel Speed
39 km/hr (24.2 mph)
Engine Model
Cummins B4.5
Bucket Range
.61 m3 / .80 yd3
Swing Speed
9.5 rpm
Travel Speed (MPH)
10 km/hr (6.2 mph) / 39 km/hr (24.2 mph)
Max. Digging Depth (FT/IN)
5,760 (18' 11")
Max. Digging Reach
8,910 (29' 3")
Tail Swing Radius (FT/IN)
2,720 (8' 11")
