Description
Hyundai large breakers are suited to fit excavators ranging from 30 ton to 80 ton. If equipped on a Hyundai excavator, standard equipped mounting brackets are designed to match up perfectly with the Hyundai linkage. If you would like to use on another brand of excavator, Hyundai dealers can match a custom mounting bracket to fit any machine.
Specifications
Manufacturer
Hyundai
Model
HDB800
Year
2026
Category
Breakers
Subcategory
Large Breakers
Operating Weight (Top Box BKT)
5625 kg (12401 lb)
Impact Power
16200 Ft Lbs (22000 J)
Suitable Excavator
55~100 ton (121254~220462 lb)
Overall Length (w/STD MTG BKT)
4059 mm (159.8 inch)
Overall Length (wo/MTG BKT)
3505 mm (138 inch)
Chisel Out Dia
200 mm (7.9 inch)
Chisel Length
1700 mm (66.9 inch)
Setting Pressure
240 kgf/cm<sup>2</sup> (3414 psi)
Working Pressure
150~190 kgf/cm<sup>2</sup> (2134~2702 psi)
Oil Flow
320~450 lpm (322~119.9 gpm)
Blow Rate (H/ Speed)
230~370 (300~480) BPM
Back Head N2 Gas Pressure
11 kgf/cm<sup>2</sup> (156 psi)
