Description
Hyundai midsize breakers are suited to fit excavators ranging from 14 ton to 25 ton. If equipped on a Hyundai excavator, standard equipped mounting brackets are designed to match up perfectly with the Hyundai linkage. If you would like to use on another brand of excavator, Hyundai dealers can match a custom mounting bracket to fit any machine.
Specifications
Manufacturer
Hyundai
Model
HDB140
Year
2026
Category
Breakers
Subcategory
Midsize Breakers
Operating Weight (Top Box BKT)
929 kg (2048 lb)
Operating Weight (Side BKT)
773 kg (1704 lb)
Impact Power
2000 Ft Lbs (2730 J)
Suitable Excavator
10~15 ton (22046~33069 lb)
Overall Length (w/STD MTG BKT)
2225 mm (87.6 inch)
Overall Length (wo/MTG BKT)
1962 mm (77.2 inch)
Overall Length (Side BKT)
1903 mm (74.9 inch)
Chisel Out Dia
105 mm (4.1 inch)
Chisel Length
975 mm (38.4 inch)
Setting Pressure
190 kgf/cm<sup>2</sup> (2702 psi)
Working Pressure
120~160 kgf/cm<sup>2</sup> (1707~2276 psi)
Oil Flow
90~110 lpm (24~29 gpm)
Blow Rate (H/ Speed)
350~550 (500~ 750) BPM
Back Head N2 Gas Pressure
12 kgf/cm<sup>2</sup> (171 psi)
